Three axis welding positioner of welding robot

Description of welding robot three axis welding positioner:

A) Three axis servo positioner of welding robot includes: servo motor drives displacement in horizontal direction and servo motor drives displacement in two vertical directions;

B) Horizontal servo motor drives the rotary disc of positioner with diagonal length of 2m-2.5m (optional) and load capacity of 800kg;

C) The load capacity of vertical positioner is 400kg;

D) The modified three-axis welding positioner can be connected with various types of welding robots and has its own control system;

E) The positioner model is suitable for welding school seats. Each cycle can complete a set of desks and chairs to replace the workload of four welders.

F) The above tooling is pneumatic clamping fixture or manual fixture (option), and users can choose according to their actual needs and capital situation.
